Detailed vehicle parameters
| Main technical data of agricultural three-wheeled 1.5-2 cubic mixer truck |
| product name |
Agricultural three-wheeled 1.5-2 cubic mixer truck |
Dimensions (mm) |
3020×1540×1536 |
| Number of axes |
2 |
Cargo compartment size (mm) |
×× |
| Number of tires |
5 |
Stirring volume |
1.5-2 cubic |
| Total mass (kg) |
2500 |
Number of springs |
4/5/6 |
| Rated mass (kg) |
1030 |
Front and rear bridge |
1.5 ton front axle 2.5 ton rear axle |
| Curb weight (kg) |
1020 |
Maximum speed (km/h) |
50 |
| Emission Standards |
Kunji |
| engine |
|
| Tank parameters of agricultural three-wheeled 1.5-2 cubic mixer truck |
| Tank material |
Alloy steel (special wear-resistant material — increase tank life more than 3 times) |
Body material |
16 manganese steel 6mm alloy steel |
| Blade material |
Baosteel 520 5mm alloy steel (add wear strip to increase service life) |
Head material |
8mm alloy steel |
| Reducer |
German ZF reducer / Italian Bonfiglioli PMP (net import) |
Hydraulic system |
Rexroth, Germany, Eaton, Sao, PMP, Italy (net import) |
| water supply system |
400L water tank air pressure water supply |
cooling system |
Kaitong radiator/Xinxiang radiator |
| Feeding speed |
Feeding speed m3/min≥3 |
Discharge speed |
Discharge speed m3/min ≥ 2 |
| Residual rate of discharge |
Residual rate of discharge (%) ≤0.5 |
Operation stand method |
Three cubic operation on the left and right sides and the cab |
| Unloading range |
180° up, down, left and right height adjustment |
safety devices |
Installation of leakage receiving device |
