Yunnei 130 horsepower engine, YN38CRE1, power 95KW, National V emission standard, 2030 single-row cab, 8.25R20 steel tire, single storage beam, air brake, ABS, 6-speed gearbox. The effective volume of the tank is produced according to the national standard: 8.27 cubic meters (8.27 tons of water)

The tank is made of 4mm thick WISCO special plates, and the actual volume is 11.8 cubic meters. The sprinkler is equipped with front flushing (spraying) and rear sprinkling as standard. The sprinkler width is ≥14 meters, with side spraying, and a working platform behind the tank. Greening sprinklers are installed on the platform. The cannon and sprinkler can be rotated in all directions, with a range of ≥28 meters, and can be continuously adjusted into straight, heavy rain, light rain, drizzle, with safety guardrails, equipped with special sprinkler pumps, pumps can be self-priming and self-draining, filter screens, with fire protection The interface can enter water through a fire hydrant, with a self-flow valve, with self-priming and self-draining function, vertical suction ≥ 7 meters;

232 partial double girder, the engine can choose Chaochai 170 horsepower and Yunnei 150 horsepower, power rotation, clutch assist, exhaust brake and air brake, air conditioning electric window central control lock, ABS. Sprinkler width ≧14-16 meters, range ≧25-30 meters, water diversion time <5min, flow rate 60m3/h. Front flush (spray), back spray, with side spray (shower), with back working platform,

It adopts the original Dongfeng chassis, D6 Dolica front tilting cab, 3308mm wheelbase, Quanchai 115 horsepower National V diesel engine, Wanliyang 5-speed gearbox, 7.00-16 tires, dynamic rotation, air brake, direction assist, ABS.

Yuchai 160 horsepower, five-speed with auxiliary gearbox, wheelbase 3950, front axle 2.8 tons, rear axle 7.65 tons, 9.00R-20 tires, 232mm beam, ABS, sprinkler special part by tank, water pump, power take-off , Transmission shaft, ball valve, spraying device and other components. The tank is made of 4mm thick WISCO special plates, and the actual volume is 11.8 cubic meters. The sprinkler is equipped with front flushing (spraying) and rear sprinkling as standard. The sprinkler width is ≥14 meters, with side spraying, and a working platform behind the tank. Greening sprinklers are installed on the platform. The cannon and sprinkler can be rotated in all directions, with a range of ≥28 meters, and can be continuously adjusted into straight, heavy rain, light rain, drizzle, with safety guardrails, equipped with special sprinkler pumps, pumps can be self-priming and self-draining, filter screens, with fire protection The interface, water can be fed through a fire hydrant, with a self-flow valve, with self-priming and self-draining functions.

The Kama 5-square sprinkler is basically equipped with a Weichai 110 horsepower engine, a 3300 wheelbase, a five-speed gearbox, a 6-ton rear axle, 7.50R16 steel wire tires, ABS, and an air brake with direction assistance.

It adopts Dongfeng original chassis, Dolica D9, fat Yubai, wheelbase 3950, 2315 row semi-front flip cab, engine Yuchai 160 horsepower, Dongfeng 6-speed gearbox, front and rear axles 3.9/8T, frame 250, tires 9.00R20 Steel tyre, direction assist, air brake, power window, central lock, ABS, air conditioner.

Chassis configuration: adopts Dongfeng Yuhu chassis, white row semi-turnable cab, Yuchai 130 engine, Jiangkai 5-speed transmission 3950 cases, axle belt mm, 9 tons rear axle, 9.00R20 original steel tires, original Factory abs, with direction boost, clutch booster, air brake. The vehicle is equipped with a special sprinkler pump (maximum vertical suction range is 6 meters), the sprinkler width is 14 meters, and the range is 28 meters. The multi-function sprinkler is equipped with 2 front sprays (can wash away mud, dust and garbage on the road); 2 rear sprays (can evenly spray water on the road, a spray width of 14 meters), 2 side sprays (Sprinkler) (can evenly water the roadside green belt), with a rear working platform, and a green sprinkler cannon installed on the platform (the cannon has heavy rain, moderate rain, drizzle, and fog can be adjusted to wash tall trees) , With 1 fire-fighting joint, 1 gravity valve, 1 filter device, humanized ladder and side guard rail, and sprinkler music horn installed.

Dongfeng Duolika D7, fat jade white, 2030 single-row chassis, engine Yunnei 130 horsepower, gearbox 6A120 (6TS55), front and rear axle 2.5/4.5 frame 192, leaf spring 8/10+7, tires 7.00-16 tires, Rotation, clutch air assist, air brake, dryer, ABS, front and lower protection. The tank volume is 8.5 cubic meters. The 4mm high-quality carbon steel plate of Wuhan Iron and Steel Co., Ltd. is used for one-step rolling and forming, which is completely seamless. The tank body is equipped with multiple anti-wave partitions, and high-pressure gas leak testing is used to make the tank body have high strength, stable center of gravity, and safe and stable vehicle transportation. The outside surface of the tank is painted, the tank body and each bumper are pasted with red and white visual reflective strips, the two sides of the tank body are sprayed with the words "green sprinkler" (the words can be painted according to your requirements), and the color of the tank body is silver gray silver blue or upper White under blue (can be painted according to your requirements).

Single row with sleeping cab, with direction assist, ABS, with original air conditioner, wheelbase 4700 9.00R20 steel tires, six-speed gearbox, Kangji 180 horsepower engine, tank volume 15 cubic meters
