Qingling Isuzu Wrecker Truck
Features:
Qingling Blue Wrecker Truck (CLW5041TQZQ5), chassis model QL1040A6HAY, emission standard GB17691-2005 Euro V GB3847-2005
Detailed vehicle parameters
| Main technical data of Qingling Blue Wrecker Truck (CLW5041TQZQ5) | |||
| product name | Qingling Blue Wrecker Truck (CLW5041TQZQ5) | Dimensions (mm) | 5415×2030×2500 |
| Chassis model | QL1040A6HAY | Cargo compartment size (mm) | ×× |
| Front passenger | 2 | Rated passenger (person) | |
| Total mass (kg) | 4495 | Approach/departure angle (°) | 24/19 |
| Rated mass (kg) | Front suspension/rear suspension (mm) | 1015/1040 | |
| Curb weight (kg) | 4050 | Maximum speed (km/h) | 98 |
| Emission Standards | GB17691-2005 Euro V, GB3847-2005 | ||
| Vehicle description | The lifting weight is (kg): 315. The side protection and rear protection of the vehicle are of apron structure, and the side and rear lower skirts interfere with the protection, so the protection can be exempted. Protective material: Q235A carbon steel, vertical connection method: The left and right sides and the lower rear skirt are all welded together. The height of the side skirts from the ground is 330mm, and the height of the rear lower skirts from the ground is 370mm. The model of ABS and its controller is: APG3550500A4, and the manufacturer is: Zhejiang Asia-Pacific Mechanical and Electrical Co., Ltd. | ||
| Chassis parameters of Qingling Blue Wrecker Truck | |||
| Chassis model | QL1040A6HAY | Fuel type | diesel fuel |
| Number of axes | 2 | Front track (mm) | 1377 |
| Wheelbase (mm) | 3360 | Rear track (mm) | 1425 |
| Number of tires | 6 | Tire specifications | 7.00R16 8PR |
| Engine Parameters of Qingling Blue Wrecker Truck | |||
| engine model | Engine manufacturer | Displacement (ml) | Power (kw) |
| 4KH1CN5LS 4KH1CN5HD |
Qingling Isuzu (Chongqing) Engine Co., Ltd. Qingling Isuzu (Chongqing) Engine Co., Ltd. | 2999 2999 |
72 96 |
